DEEPCOOL CH170 DIGITAL MINI-ITX (WHITE)
About this item : CH170 DIGITALThe CH170 DIGITAL is a vertical ITX case that has all the hallmarks of a high-airflow DeepCool case but in a tiny footprint. The internal layout provides a lot of flexibility for coolers and PSU options.
DEEPCOOL CH170 DIGITAL MINI-ITX (WHITE)
The CH170 DIGITAL WH is a vertical ITX case that has all the hallmarks of a high-airflow DeepCool case but in a tiny footprint. The internal layout provides a lot of flexibility for coolers and PSU options.
HIGH AIRFLOW PANELS
Mesh panels surround the CH170 DIGITAL WH from every side and create a high-airflow, small-form-factor case like no other.
NO ADDED GPU LATENCY!
Designed to accommodate most 65mm thick dual-fan GPUs that are shorter than 305mm in length and up to 138mm in width, it can be directly inserted into the motherboard without the assistance of a riser cable—no added GPU latency concerns!
Maximum GPU Length Based on PSU:
SFX/SFX-L：305mm
ATX：230mm
| Model Number | DEEPCOOL CH170 DIGITAL MINI-ITX (WHITE) |
| Product Dimensions | 250x200x380mm(L×W×H) |
| Net Weight | 3.4Kg |
| Materials | ABS+SPCC |
| Motherboard Support | Mini-ITX |
| Front I/O Ports | USB3.0×2、Audio×1、Gen2 TypeC×1 |
| 3.5" Drive Bays | 1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three） |
| 2.5" Drive Bays | 1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three） |
| Expansion Slots | 3 Slots |
| Pre-Installed Fans | None |
| Fan Support | Top:1×120 mm Front: NA Rear: 2×120 mm Bottom:1×120 mm Side : 2×120 mm |
| Radiator Support | Side : 240mm |
| CPU Cooler Height Limit | 172mm |
| GPU Size Limit | Length: SFX/SFX-L: 305mm / ATX: 230mm Height: 138mm Width: 65mm (3 Slots) |
| Power Supply Type | ATX PS2（maximum length: 140mm）/ SFX / SFX-L |
| EAN | 6933412774211 |
| P/N | R-CH170-WHNPI0D-G-1 |
| Brand | DEEPCOOL |
| Info | DEEPCOOL is dedicated to provide the best Laptop Cooler,CPU coolers and PC Power Supply. |
